LAUNCH X431 PRO3 LINK SmartLink V1.0 Commercial Vehicle Diagnostic Tool
The X-431 PRO3 LINK HD diagnostic scan tool combines robust hardware with exceptional software services, specifically engineered for commercial vehicle repair and diagnostics.
Key Features
- • Modular design enables faster vehicle system access
- • Integrated X-431 Fix database for problem resolution
- • Software available for separate purchase via Mall
- • Comprehensive heavy-duty diagnostic coverage
- • Capable of diagnosing light, medium & heavy-duty vehicles
- • Multiple connection options: USB, Bluetooth, Wi-Fi
- • Standard functions: Read/clear DTC, VIN scan, wireless connection, diagnostic records, bi-directional tests
- • Smartlink Remote Diagnosis support
- • Optional ADAS HD calibration for additional revenue streams
- • 21 Advanced Service Functions: DPF Regen, Parameter Setting, Cylinder Deactivation, Oil Reset, Injector Coding, Speed/Idle Adjustment, Fan Calibration, Remote Throttle, Urea Drive, DTC Clearing, Flash Conversion, Brake Reset, Transmission Replacement, Nox Reset, Aftertreatment, Immobilizer, Suspension, Odometer, Language/PTO Change
- • Expandable Toolbox: Oscilloscope, Sensorbox, Battery Tester, Videoscope, Wi-Fi printer
Vehicle Coverage
AGCO HD, AISIN HD, Allison HD, Ashok Leyland HD, Astra HD, Bendix_ABS HD, CASE HD, Caterpillar HD, Credo HD, Cummins, Detroit HD, DEUTZ HD, Doosan HD, Eaton HD, EICHER HD, ERF HD, FLEXICOIL HD, Freightliner HD, USAFORD DS, Fuso HD, Haldex_ABS HD, HATZ HD, Hino HD, HITACHI HD, Hyundai HD, International HD, IrisBus HD, Irizar HD, Isuzu HD, Iveco HD, JAC HD, JCB HD, John Deere HD, Kenworth HD, KNORR HD, LIEBHERR HD, Mack, Mahindra HD, Man HD, Maxxforce HD, Mercedes-Benz HD, Miller HD, Mitsubishi DS, MWM HD, Neoplan HD, NEW HOLLAND HD, Nissan DS, OBD HD, Paccar HD, Perkins, Peterbilt HD, PSI HD, Renault HD, Scania, Setra HD, Sitcar HD, Sterling HD, Steyr HD, Tata HD, Toyota DS, TRAILER HD, UD, VOITH HD, Volvo HD, Wabco_ABS HD, ZF HD, etc.
Currently includes 120 diagnostic software packages with continuous updates.
Technical Specifications
| X-431 PRO3 LINK HD (Tablet) | |
| Operating System | Android 10.0 |
| Display | 10.1", 1280×800 resolution |
| Processor | 2.0GHz Quad-Core CPU |
| Memory | 4GB RAM |
| Storage | 64GB internal storage |
| Battery | 47.88Wh (7.6V, 6300mAh) |
| Camera | 8MP rear camera |
| VCI Connection | Dual-band 2.4GHz/5GHz |
| Dimensions | 274 × 190.5 × 40.5 mm |
| Interfaces | 1 × USB Type A, 1 × USB Type C |
